12V DC PUMP IMPELLER TYPES
PRODUCT DETAILS
- Shower debris presents no problem to this bronze bodied, flexible impeller design
- Simple design means fewer wearing parts-all user serviceable
- Complies with USCG 183.410 and ISO 8846 MARINE (ignition Protection)
- ISO 8849 MARINE (Bilge Pump Standard)
- Compact size - easy to install, operation and maintenance
- Noise absorbing mounts
- Thermal overload (Safety and reliability)
APPLICATION
- Used in marine to drain water on deck and wash deck
- Should be installed in a dry and ventilated position
- Must not run dry, its better work with a bilge control panel to avoid running dry
FEATURES
- Good flow rate, 8.5 gpm (32 lpm) at 10ft (3m) total head
- Self -priming up to 4ft (1.2m) allows
- Pump Body: Brass (Treated against corrosion)
- High Grade Stainless Steel motor Shaft
- Mounting above wet bilges
- Easy installation
- Bronze body and flexible impeller
- High flow and excellent suction
- Bilge debris presents no problem to this bronze bodied,flexible impeller design
TECHNICAL DATA
Body Material: Bronze
Impeller:NBR Rubber
Seal:Lip Type
Ports:3/4" Female Thread(FNPT)
Volatege:12V/24V DC
Motor:Permanent Magnet Type Fully Enclosed Stainless Steel, High quality seamless design
Self-Priming:3.0m vertical lift
Pressure:can generate pressures up to 2 bar(30psi)
Model |
Flow Rate (LPM) |
Volts (V) |
Max Lift (M) |
Max Draw (A) |
Packing Size (MM) |
N.W/G.W (KG) |
SF-32-12 |
30LPM |
12V |
3M |
10.0A |
215*135*110 |
2.38/2.58 |
SF-32-24 |
30LPM |
24V |
3M |
7.0A |
215*135*110 |
2.38/2.58 |
