12 VDC RV WASTE PUMP RV SEWAGE PUMP
The powerful Macerator FL-65A is compact, making it perfect for tight spaces in RVs, boats and campers. Customers will come to appreciate the performance this system delivers. The twin stainless steel blades and high performance impeller materials allow the pump to empty a 20-gallon holding tank in about 2 minutes. Other design features include abusive duty cycles, intermittent dry running, self-priming, and thermal protection.
It is designed specifically for sanitation waste and fish box evacuations. This high-powered pump incorporates our high quality motor with a new seamless shell and splash proof design. The Macerator features a premium impeller design and includes o-ring sealed end bells with a sealed manual turn key to withstand the harsh marine environment.
Dual blade and housing construction ensures problem free pumping, providing superior performance while delivering up to 12 GPM [45.00 LPM]. Available in 12, 24, 115 and 230 Volts.
SPECIFICATIONS
Liquid Temperature:140°F (60°C) Max.
Priming Capabilities: Not needed flooded suction
Power: 9 amps max current draw
Max Pressure: Not needed
Inlet/Outlet Ports:1.5” (39mm) quick connector or thread fitting
Weight: 4.9 lbs (2.24 kg)
Motor Type: High quality seamless design that is thermally protected
Leads: Wire leads
FEATURES
12GPM(45.00LPM)
Self Priming
Seamless Motor Shell
O-Ring Shaft Seal
Heavy Duty Shaft Seal
Manual Turn Key With Rear O-Ring Seal
Innovative Internal Housing Design
Dual Blade Design
Premium Impeller
Ignition Protection
Thermally Protected
Available in 12, 24, 115 and 230 Volts
TECHNICAL DATA
Model
Volts(V)
Open Flow GPM(LPM)
Amps Max(A)
Packing Size(mm)
N.W/G.W
FL-65A
12
12.0(45.0)
9.0
320*135*110
2.10/2.40
FL-65B
24
12.0(45.0)
6.0
320*135*110
2.10/2.40
APPLICATION
GRAY AND BLACK WATER HAVE MET THEIR MATCH.
Typical Applications: RV Industrial and Ag
