Marine Self-priming Bilge Pump
MORE FEATURES FOR AUTOMATIC BILGE PUMP
- All-in-one pump & switch - No float switch required
- Pump turns on when water level rises & shuts off when water is removed
- Water cooled motors for long life, with anti airlock design and moisture tight seals.
- Output: Up to 12.5 gallons/minute(750 gallons/hour). Max. recommended discharge head 2.5m.
- Heavy duty motors with stainless steel shafts and tough thermoplastic bodies.
- Includes comprehensive user manual with installation instructions and wiring diagram
- Snap-off strainer for easy cleaning
- Connections: For 19mm (3/4") bore hose for 600GPH &750GPH, 29mm hore hose for 1100GPH
- Totally submersible and ignition protected.
- Compact pump for smaller vessels.
- Tough plastic body.
- Limited one year warranty
- Can be used with switch panel for manual override
- Includes comprehensive user manual with installation instructions and wiring diagram
MORE APPLICATION
- Typically used in boat hulls / bilges
- Bait tanks
- Ponds, pools, spas
- Other applications where you have to remove water from
- Note: These pumps are designed for intermittent use only, NOT designed for continuous use
- Note: Bilge and aerator pumps must be lower than the source of water for priming
TECHNICAL DATA
DIMENSION DRAWING
Sample order is very welcome to have a test, if need more technical specification, pls send email to us !
